Plate Magnet

Plate Magnets are designed for use in chutes and suspension over conveyed product. Installed on the bottom side of a chute, a Plate Magnet will provide maximum protection as product travels through the powerful magnetic circuit. The magnetic field projects from the face of the Plate Magnet reaching into the product stream and pulling the ferrous contaminants to the magnet face. The magnetic field on a Plate Magnet is strongest at the surface and gets weaker the further you move away.

Permanent Magnetic Plates are designed in various sizes & strengths to meet with specific operation & plant conditions. Magnetic Plates are widely used for removing Tramp iron such as Bolts, Nuts, Bits of Wire, Nails and other casual containmination from free flowing materials to protect against occasional damage to the plant caused by bits of iron.

Plate Magnets can ideally be used to remove tramp iron from the moving material carried in chutes ducts, spouts or on conveyor belts, screens and feed trays. Whether the material is plastic or paper pulp, food or fertilizer, Oil seeds or gains the result is sure protection of processing machinery and iron free final products
